Oil Fired Water Tube Hot Water Boiler

Oil Fired Water Tube Hot Water Boiler

Gas(oil) Fired Water Tube Hot Water Boiler

Product parameters:

Rated thermal power: 10.5-70Mw

Rated thermal efficiency: 95-98%

Pressure: ≤2.5MPa

Available fuel: natural gas, city gas, LPG, etc.

Product description:

The boiler is a double-drum longitudinal “D” type structure. The water, steam or steam-water mixture flows in the tubes. The flame burns and the flue gas flows outside the tubes, to ensure the good water circulation system, thus ensuring the long-term stable operation of the boiler.

Product advantages:

High efficient heat transfer

The boiler adopts a countercurrent arrangement, the furnace volume is selected reasonably, and the fuel is fully combusted.

Less heat loss

Aluminum silicate felt and ultra-fine glass wool insulation material with a total thickness of 200mm, the heat loss of the boiler is minimized.

Strong power failure protection

The boiler uses gas (oil) fuel, which has a low vaporization rate and a strong ability to protect the boiler.

Easy to install and maintain

The boiler is designed and assembled with short installation period and convenient disassembly for post-maintenance and inspection.

Oil Fired Water Tube Hot Water Boiler Anatomy

Gas(oil) Fired Water Tube Hot Water Boiler Anatomy
Oil Fired Split Hot Water Boiler

Oil Fired Split Hot Water Boiler

Gas(oil) Fired Split Hot Water Boiler

Product parameters:

Rated thermal power: 0.7-14Mw

Rated thermal efficiency: 91-96%

Pressure: ≤1.25MPa

Available fuel: natural gas, light oil, etc.

Product description:

This series of boilers adopts a downstream, three-pass and shell design to ensure that the fuel is fully combusted in a large combustion chamber, and fuel utilization and boiler efficiency are greatly improved.

Product advantages:

Fully automatic control

The computer’s full-range analog control is more convenient for both normal operation and post-maintenance maintenance.

Strong load adaptability

The boiler has a large water volume and can be used normally for users with a wide range of load changes.

Small footprint

The layout of the boiler is reasonable, which reduces the overall volume of the boiler and the investment cost of the boiler house.

High thermal efficiency

The low-resistance and high-efficiency heat exchange component, the threaded pipe, replaces the traditional light pipe and improves the thermal efficiency of the boiler.

Oil Fired Split Hot Water Boiler Anatomy

Gas(oil) Fired Split Hot Water Boiler Anatomy
Oil Fired Integrated Hot Water Boiler

Oil Fired Integrated Hot Water Boiler

pro 128

Product parameters:

Rated thermal power: 0.7-14Mw

Rated thermal efficiency: 96-98%

Pressure: ≤1.25MPa

Available fuel: natural gas, light oil, etc.

Product description:

This series of boilers mainly use condensing technology to recover the residual heat of flue gas, making full use of the sensible heat and latent heat of flue gas. The boiler absorbs a large amount of heat again, so the exhaust gas temperature is only 50 °C, and the thermal efficiency can be increased by more than 10%, which can save at least 4% of fuel input.

Product advantages:

Low nitrogen, environmental protection

Through the integrated solution of waste heat utilization, the exhaust gas temperature is <90 °C, reducing the emission of harmful substances.

Stable operation

The unique differential pressure detection and variable frequency continuous water supply system is more sensitive to the induction of boiler operation changes.

High efficiency and energy saving

The boiler heating surface is arranged reasonably, the heat transfer area is sufficient, and the thermal efficiency can reach 98%.

Easy to operate

The boiler is equipped with a PLC intelligent operating system, which can automatically start the furnace, adjust the parameters and shut down the furnace after starting.

Oil Fired Integrated Hot Water Boiler Anatomy

Gas(oil) Fired Integrated Hot Water Boiler Anatomy
Electric Steam Boiler

Electric Steam Boiler

pro 132

Product parameters:

Rated thermal power: 0.5-4.0 t/h

Rated thermal efficiency: 98%

Pressure: ≤1.25MPa

Available fuel: electric energy

Product description:

The boiler is composed of furnace, water supply, self-control, heating and safety protection system. It uses electricity to generate heat and generate steam with a certain pressure. It has the characteristics of convenient use, simple operation, economical and wide application fields.

Product advantages:

No pollution, no noise

The boiler has no combustion chamber, no chimney, no need to consider heat loss, and the thermal efficiency is above 98%.

Multiple protection system

The boiler has multiple protections such as voltage, water level, power supply and pressure, which is safe and reliable.

Small footprint

Adopt scientific and reasonable design structure and advanced manufacturing process to reduce boiler space and save the use of the site.

Long service life

The boiler operation period can be set as required, and each heating group can be automatically time-divisionally activated to extend the service life of the equipment.

Electric Steam Boiler Anatomy

Electric Steam Boiler Anatomy
Electric Hot Water Boiler

Electric Hot Water Boiler

Electric Hot Water Boiler

Product parameters:

Rated thermal power: 0.1-2.8Mw

Rated thermal efficiency: 98%

Pressure: ≤1.0MPa

Available fuel: electric energy

Product description:

The boiler is composed of a boiler body, an electric control box and a control system, and has obvious characteristics of environmental protection, cleanliness, pollution-free, noise-free and automatic. With the reduction of limited energy and the sharp rise in price, electric hot water boiler as a new type of kinetic energy equipment is more and more recognized by people.

Product advantages:

Simple operation

Use the controller keyboard to check, set and modify parameters, easy to understand, easy to learn, easy to remember, easy to operate.

High economic efficiency

Use night low valley electricity to heat the water to 95 ° C, and then use heat exchanger heat exchange to save power consumption.

Long-term stable operation

The heating pipe is immersed to avoid burning due to the exposure of the root of the heating pipe to ensure long-term operation of the boiler.

Long service life

The ceramic electric heating rod is used for uniformity and high thermal efficiency to prevent potential safety hazards.

Electric Hot Water Boiler Anatomy

Electric Hot Water Boiler Anatomy
V6 Oil Fired Hot Water Boiler

V6 Oil Fired Hot Water Boiler

pro 139

Product parameters:

Rated thermal power: 99Kw

Rated thermal efficiency: 97.2-104.4%

Pressure: 1.0MPa

Available fuel: natural gas

Product description:

This series of boilers is a vertical structure. It uses advanced condensation technology to achieve condensation without a economizer. The overall footprint is only 1.4m³, and the exhaust temperature is as low as 50°C. It can continuously deliver hot water to schools, shopping malls, hotels, offices and other places.

Product advantages:

Intelligent modular system

The control system can preset multiple boilers to control the number of boilers and the operating status according to the requirements.

High efficiency and energy saving

Highly advanced condensing technology ensures efficient energy use and boiler operating efficiency is increased to 104%.

High combustion efficiency

The unique full premixed combustion system greatly improves the fuel’s combustion efficiency; it also reduces COx and NOx emissions.

To meet drinking water standards

The boiler is built with a food grade enamel coating. The effluent meets the drinking water standard and has anti-corrosion, anti-rust and anti-shedding properties.

V6 Oil Fired Hot Water Boiler Anatomy

V6 Gas Fired Hot Water Boiler Anatomy
T7 Oil Fired Hot Water Boiler

T7 Oil Fired Hot Water Boiler

T6 Vacuum Hot Water Boiler

Product parameters:

Rated thermal power: 2.8-7.0Mw

Rated thermal efficiency: ≥105.5%

Pressure: -0.02MPa

Available fuel: natural gas

Product description:

The deep matched technology of new combustion and heat transfer no longer sacrifices the boiler’s key characteristics (heat transfer system) to adapt to the burner characteristics (combustion system), making the gas boiler a complete thermal system with low nitrogen emissions. At the same time of obtaining low nitrogen emission, the utilization efficiency of the boiler is further improved.

Product advantages:

Intelligent modular system

The boiler has single, series and parallel use modes, and the system can automatically adjust the number and status of boiler operation.

All-terrain applicability

The use space of the furnace is increased, and it can be used normally under the conditions of high cold, high altitude or high temperature.

The floor space is very small

Using the wing condensing technology, the overall area of the boiler is greatly reduced while ensuring the efficiency of the change.

Simple operation

The boiler is equipped with a high-color touch screen, dynamic graphic display, multi-level menus and permissions, and automatic fault record keeping.

T7 Oil Fired Hot Water Boiler Anatomy

T7 Gas Fired Vacuum Hot Water Boiler Anatomy
T6 Oil Fired Hot Water Boiler

T6 Oil Fired Hot Water Boiler

T6 Vacuum Hot Water Boiler

Product parameters:

Rated thermal power: 0.7-2.8Mw

Rated thermal efficiency: 105.5%

Pressure: -0.02MPa

Available fuel: natural gas

Product description:

The boiler adopts an environmentally friendly combustion method – full premixed combustion, and the gas and air are precisely adjusted and premixed in advance to ensure more complete combustion. The new crossing wing-shaped heat exchange element, Ultra-speed Smoke Cooking Tube, uses a unique heat transfer technology and structural design to achieve deep condensation of flue gas and greatly improve heat transfer efficiency.

Product advantages:

Small footprint

The heat exchange surface of the boiler is sufficient, and the condenser and the rear smoke box are integrated to reduce the total volume of the boiler.

High efficiency

The flow rate of the flue gas in each section is stable, and the utilization rate of the heat exchange surface is improved.

A multi-purpose machine

The boiler adopts standard pipe box, adapts to single and double circuit, different temperature and other modes, and realizes multi-channel water supply.

Long service life

The heat medium in the boiler is deoxidized and descaled, and there will never be scaling and corrosion. The normal service life can reach more than 20 years.

T6 Oil Fired Hot Water Boiler Anatomy

T6 Gas Fired Vacuum Hot Water Boiler Anatomy
H6 Oil Fired Hot Water Boiler

H6 Oil Fired Hot Water Boiler

H6 Gas Fired Hot Water Boiler

Product parameters:

Rated thermal power: 0.7-2.8Mw

Rated thermal efficiency: 97.2-106%

Pressure: 0.1MPa

Available fuel: natural gas

Product description:

The boiler adopts advanced full premixed combustion technology to achieve super high utilization of fuel, and the operating efficiency is increased by more than 15% compared with ordinary boilers. The integrated structure design reduces the floor space by more than 30%. It is the preferred equipment for energy-saving heating in hotels, shopping malls and schools.

Product advantages:

Ultra high heat transfer efficiency

The winged heat exchange element, the unique tear groove design increases the heat exchange area by 5 times, and the heat transfer efficiency is superior.

Very simple installation

Boiler installation design, in-plant commissioning, user site only need to install in and out of water pipes, chimneys, gas pipes and power, you can use.

Compact structure and small size

By optimizing and improving the boiler and burner structure, the boiler body is greatly reduced to only 40% of the volume of an ordinary hot water boiler.

Ultra low nitrogen emissions

Effective control of pollutant emissions through the use of full premixed combustion technology and condensate at the end of the boiler.

H6 Oil Fired Hot Water Boiler Anatomy

H6 Gas Fired Hot Water Boiler Anatomy
Oil Fired Water Tube Steam Boiler

Oil Fired Water Tube Steam Boiler

Gas(oil) Fired Water Tube Steam Boiler

Product parameters:

Rated thermal power: ≥10t/h

Rated thermal efficiency: 100-104%

Pressure: ≤2.5MPa

Available fuel: diesel, heavy oil, natural gas, city gas, liquefied petroleum gas, etc.

Product description:

The boiler adopts a double-drum longitudinal “D” type arrangement structure; water, steam or steam-water mixture flows in the pipe; flame burns and flue gas flows outside the pipe, forming extremely fast steam-water flow rate and excellent water circulation system. Boiler heat absorption rate and thermal efficiency are high.

Product advantages:

The boiler quality is good

More than 95% of automatic welding equipment is used. Each boiler is tested and quenched before leaving the factory. The qualified rate of inspection is 100%.

Meet large evaporation requirements

The furnace is placed outside the cylinder, and the volume of the furnace can be large or small to meet the requirements of combustion and large evaporation.

Efficient heat transfer

The drum is not directly heated, and the tube containing the water vapor is placed in the furnace and the flue as a heating surface to improve heat transfer efficiency.

Small impact of the disaster

The special water pipe arrangement increases the heating surface, but the amount of boiler water is not much. In the event of a disaster, the degree of damage is small.

Oil Fired Water Tube Steam Boiler Anatomy

Gas(oil) Fired Water Tube Steam Boiler Anatomy
